Tools and Ancillaries
-
> BÜFA Tec
With our wide range of durable and efficient BÜFA Tec processing machines, we provide proven application technology – developed in-house – to support and enhance your production processes. The spectrum ranges from practical Hand Metering Pumps to complex dosing, mixing and application systems.
BÜFA Tec is happy to develop customised solutions for your specific applications together with you. Our experts work closely with you to ensure that every machine and every system is customised precisely to your specific requirements. We leverage cutting-edge technologies and innovative ideas to consistently deliver the highest levels of quality and efficiency.
Whether you are active in the automotive industry, shipbuilding, or any other area of the composites industry, BÜFA Tec is at your side as a reliable partner.
Gelcoat Spraying Units for different requirements and applications
Here you will find our Gelcoat Spraying Units as a PDF file
BÜFA®-Tec Poly-Jet Cup Gun
Experience maximum flexibility with the Poly-Jet cup gun. Thanks to its various nozzles, it is ideal for the even application of almost all types of gelcoats, regardless of their viscosity. This versatility makes the Poly-Jet cup gun the perfect choice for a wide range of applications and requirements.
Details:
- Low costs
- Simple operation
- Uncomplicated cleaning and maintenance
- Fast and even coating
BÜFA®-Tec Century Gun
Our Century gun is a central component of our systems and offers a continuous, low-emission spray jet for excellent gelcoat deaeration. It allows for easy cleaning, quick nozzle changes and various extensions without the need for rinsing after applied material.
Details:
- Continuous, low-emission spray jet for excellent gelcoat deaeration
- Peroxide mixing optionally by external mixing (EM) or internal mixing (IM)
- No rinsing process after applied material required
- Easy cleaning
- Quick nozzle change
- Low-pressure airless with auxiliary air
BÜFA®-Tec GSU ES1 2.0 EM
This gelcoat spraying unit (GSU) is ideal for small to medium-sized components of around 1-3 m², straight from the container. This unit enables the spraying of UP gelcoat resins. Resin and curing agent are mixed efficiently by means of external mixing.
Details:
- Clearly organised machine with simple operation
- Suitable for use in explosion-protected areas (pneumatic control)
- The pressurised container for peroxide allows a wide range of dosing settings
- Proven Century gun technology
- Excellent peroxide mixing due to external mixing of resin and peroxide
- Spraying different colours with the multicolour variant and extension unit
BÜFA®-Tec GSU ES1 EM Easy Lift
This version of the ES1 gelcoat spray unit (GSU) is equipped with a trolley and is therefore extremely mobile. Thanks to our innovative lifting technology, daily work is made considerably easier.
Details:
- Simple operation thanks to innovative lifting technology
- Suitable for use in explosion-protected areas (pneumatic control)
- Proven Century gun technology
- Excellent peroxide mixing due to external mixing (EM) of resin and peroxide
BÜFA®-Tec GSU 9C and 12C
These Gelcoat Spraying Units (GSU) are ideal for mobile use and make it easy to optimise the application of gelcoat. The 9C variant is well suited for small to medium-sized components and the 12C variant for medium to larger components. Both have the same air motor and transport trolley; the only difference is the size of the resin pump. The systems are available in both a two-colour and a six-colour version. We are happy to offer you other configurat
Details:
- High mobility thanks to transport trolley
- Suitable for use in explosion-protected areas
- Pneumatic control
- Proven Century gun technology
- The pressurised container for peroxide allows a wide range of dosing settings
BÜFA®-Tec 9C Omega and 12C Omega
These Gelcoat Spraying Units (GSU) are ideal for mobile use and make it easy to optimise gelcoat application. The 9C variant is well suited for small to medium-sized components and the 12C variant for medium to larger components. Internal mixing variants (IM) of these Gelcoat Spraying Units are also available.
Details:
- Mobile Omega chassis
- Suitable for use in explosion-protected areas
- Pneumatic control
- Proven Century gun technology
BÜFA®-Tec GSU Delta
This Gelcoat Spraying Unit (GSU) offers proven application technology for your production processes: Gelcoat application directly from the container, suitable for medium to large components. Our innovative delta pump technology for resin and Peroxide ensures excellent Peroxide mixing.
Details:
- System optionally available with standard chassis, EVO-Line chassis or for wall mounting
- Clearly organised machine with simple operation
- Low pulsation thanks to the quick-changeover valve technology
- Proven filter and pulsation damper unit
- Pump seals available for abrasive materials
- Suitable for use in explosion-protected areas (pneumatic control)
- Proven Century gun technology
BÜFA®-Tec GSU Sigma 6
This Gelcoat Spraying Unit enables gelcoat to be sprayed directly from the container and is suitable for medium to very large components. Thanks to our innovative Sigma pump technology for resin and peroxide, excellent peroxide mixing is guaranteed.
Details:
- Clearly organised machine with simple operation
- Low pulsation thanks to the quick-changeover valve technology
- Optional pump seals available for abrasive materials
- Suitable for use in explosion-protected areas (pneumatic control)
- Proven Century gun technology
BÜFA®-Tec fibre spraying units for different requirements and applications.
Here you will find our fibre spraying units as a PDF file.
BÜFA®-Tec FSU Delta
This Gelcoat Spraying Unit (GSU) offers proven application technology for your production processes: Gelcoat application directly from the container, suitable for medium to large components. Our innovative delta pump technology for resin and Peroxide ensures excellent Peroxide mixing.
Details:
- Clearly organised machine with simple operation
- Low pulsation thanks to the quick-changeover valve technology
- Optional pump seals available for abrasive materials
- Suitable for use in explosion-protected areas (pneumatic control)
- Proven Century gun technology
BÜFA®-Tec FSU Sigma 6
Effective Fibre Spraying Unit (FSU) for almost all components and resin systems. Thanks to our innovative Sigma pump technology for resin and peroxide ensures excellent peroxide mixing. The Sigma pump is characterised by its particularly high performance.
Details:
- EVO-Line stainless steel chassis
- Century gun technology with automatic fibre cutter
- Durable design for long service life under high stress
- Low pulsation thanks to the quick-changeover valve technology
- Suitable for use in explosion-protected areas
BÜFA®-Tec Lamination Roller Systems for various requirements and applications.
Here you can find our Lamination Roller Systems as PDF
BÜFA®-Tec RRU 12C
The BÜFA®-Tec Lamination Roller System RRU (Resin Roller Unit) 12C mixes and doses precisely. You determine the pressure and quantity of the resin mixture as you need it. The resin and hardener pump are pneumatically force-coupled.
Details:
- Clearly organised machine with simple operation
- Low pulsation thanks to the quick-changeover valve technology
- Optional pump seals available for abrasive materials
- Suitable for use in explosion-protected areas (pneumatic control)
- Proven Century gun technology
BÜFA-Tec UNI 150 and UNI 275
The BÜFA®-Tec Lamination Roller System UNI 150/275 EVO-Line mixes and doses precisely. The resin and hardener pumps are pneumatically force-coupled. With the appropriate tools, the system can be used as an Injection System, Gelcoat Spraying Unit and impregnation system.
Details:
- Cost-effective Lamination Roller System
- Robust and proven pump technology
- Self-adjusting pump packings
- Process reliability thanks to built-in Gelling time warning
- Stroke counter for optimising resin consumption
- Hardener shortage protection possible on request
- Minimised detergent consumption thanks to pulse rinsing
BÜFA®-Tec Casting Systems for various requirements and applications.
Here you can find our Casting Systems as PDF
BÜFA®-Tec SSU 20C IM
Our state-of-the-art BÜFA®-Tec SSU (Solid Surface Unit) 20C IM casting system processes resin-hardener mixtures to produce high-quality end products for the sanitary sector such as bathtubs, shower trays, and sinks. The system allows the addition of a variety of fillers to customise the material characteristics.
Details:
- High filler quantity possible
- Simple production of moulded products
- Simple operation and clearly laid out machine
- Precise dosing result achieved with static mixers
BÜFA®-Tec Bonding Paste Units for various requirements and applications.
Here you can find our Bonding Paste Units as PDF
BÜFA®-Tec BPU Gamma 4
This Bonding Paste Unit (BPU) has been specially developed for processing Bonding Pastes from small containers (25 L Kegs) and is particularly suitable for the applied material of fibre-free and hollow ball-free products.
Details:
- Compact system design
- 2-component mixing head with rinsing function
- Direct removal of the Bonding Pastes from the container
- Designed to minimise leftover material in containers
- Low detergent consumption
BÜFA®-Tec BPU Theta 11
This Bonding Paste Unit (BPU) has been specially developed for processing Bonding Pastes from large containers (drums) and is particularly suitable for the applied material of fibre-free and hollow ball-free products.
Details:
- Compact system design
- Direct removal of the Bonding Pastes from the container
- Peroxide pump with spindle mechanism and infinitely variable setting
- Designed to minimise leftover material in containers
- Low detergent consumption
BÜFA®-Tec RTM Systems for various requirements and applications.
Here you can find our RTM Systems as PDF
BÜFA®-Tec RTM Delta
Our Hand Metering Pumps offer you a simple, uncomplicated method for dosing liquids such as resins, varnishes, Peroxides and many other pumpable media, directly from the container or storage tank.
Details:
- No weighing or decanting
- Increased safety and cleanliness in the workplace
- Low material losses
- No power connection required
- Available as 2-component pump for precise resin-curing agent dosing
BÜFA®-Tec Hand Metering Pumps for various requirements and applications.
Here you can find our Hand Metering Pumps as PDF
BÜFA®-Tec HDP 500 ml PP
Our Hand Metering Pumps offer you a simple, uncomplicated method for dosing liquids such as resins, varnishes, Peroxides and many other pumpable media, directly from the container or storage tank.
Details:
- No weighing or decanting
- Increased safety and cleanliness in the workplace
- Low material losses
- No power connection required
- Available as 2-component pump for precise resin-curing agent dosing
Automatic Dosing Technology for consistent quality
Here you can find our Automatic Dosing Technology as PDF
BÜFA®-Tec Polybar
Proven component Metering Pump for fast, simple and reproducible dosing without scales. The resin is pumped by a double-acting and wear-free PTFE bellows pump.
Details:
- No resin leakage
- Infinitely adjustable delivery rate
- Precise and reproducible dosing
- No material loss, no weighing and decanting
- Increased safety and cleanliness
Our stirring and mixing devices create ideal processing conditions for reactive resins. We are happy to provide further agitator models and special extensions – such as agitators with integrated diaphragm pumps – upon request.
Here you can find our Stirring & Mixing Equipment as PDF
Solutions for Customised Plant Engineering
Do you need a system that is customised to your requirements? Then BÜFA Tec Maschine-Technology is the right partner for you. Our engineers and technicians plan, supply and install solutions that are optimised to meet your requirements.
- Special installations
- Tanks, containers
- Stirring and dispersing technology
- Level and flow monitoring for reproducible and optimised process sequences
- Process data visualisation and its sustainable recording
- Holistic application systems
Service and Project Consulting
Every production process has different requirements and therefore also different service requirements. The type and age of the system, spraying or laminating performance or the number of trained personnel are just a few examples that can influence the scope of services. You can rely on our BÜFA Tec team to provide you with optimally customised support!
You decide which scope of service covers your current requirements and can therefore determine the service costs incurred together with us:
- Support of the system during the entire period of use
- Inspection of the systems by our service technician to maintain their value (1-2 times a year depending on operating times)
- Replacement of wearing parts (e.g. pump packings and seals) with subsequent functional check
- Optimised machine settings to reduce emissions and overspray
- Professional project advice from our engineers and technicians
- Training your employees with a focus on machine handling as well as maintenance and servicing
Spare Parts
Ordering spare parts is very easy at BÜFA! Just give us a call and we will send you the spare parts you require, or our service technician will install them directly at your premises.
Contact us, we will be happy to advise you!
